Water Purifier (Ion-exchange)

Water Purifier (Ion-exchange)(WL220T)

Item Code：253629

Model：WL220T

Power Source：AC100 to 240V0.2ASingle-phase

Origin：Japan

Product Summary

Economical, space saving benchtop water purifier which connects directly to tap water.

Features

Collecting deionized water is as simple as connecting to a faucet

Benchtop, space-saving design

Digital display for easy operation

Deionized water compliant with ASTM D1193 Type 2 / JIS K 0557 A3 level, suitable for trace analysis

Displays replacement of consumables

Standard equipped with membrane filter (WL200/220)

A solenoid valve at the water sampling port prevents water leakage from final membrane filter

WL220T is suitable for supplying pure water to the water tank built into constant temp. and humidity chamber

Specifications

Item Code

253629

Model

WL220T

Water purifying method

Ion-exchange (Manual)

Raw water supply

One touch coupler water connection resin hose

Deionized water production

Approx. 1L/min. (by natural fall)

Ion-exchange resin cartridge

2L ion-exchange resin with activated carbon (CPC-P) x 1pc. 2L ion-exchange resin (CPC-E) x 1pc.

Final filtration

N/A

Pure water tank

3L polyethylene tank

Water leakage detection

Solenoid valve forced shutdown of water supply by detecting water leakage

Raw water pressure range

0.5 to 5x100kPa (0.5 to 5 kgf/cm2)

Sampling port

ø9 nipple (Hose connection)

Safety device

Circuit breaker, Water leakage indicator, Pressure reducing valve, Water quality abnormal alarm

Water quality display

7 segments LED display (Conductivity / Resistivity)

Other display

Display of consumables replacement (CPC-P and CPC-E: Should be replaced simultaneously to prevent degradation of water quality, Membrane filter), Alarm display (Water leakage alarm)

Accessories

Raw water supply hose, Power cord (2m), Ion-exchange resin CPC-P+CPC-E (WL220/WL220T),

Accessories

Y-shaped water supply hose with strainer 4m (WL220T), Constant temp. and humidity chamber connection hose ø9xø13 3m (WL220T), Hook (WL220T), Seal tape

External dimensions（W×D×H mm）

350×350×450mm

Power Source

AC100 to 240V0.2ASingle-phase

Weight

17kg

Catalog
