Water Purifier (Ion-exchange)

Water Purifier (Ion-exchange)(WL200)

Item Code：253627

Model：WL200

Power Source：AC100 to 240V0.2ASingle-phase

Origin：Japan

Product Summary

Economical, space saving benchtop water purifier which connects directly to tap water.

Features

Collecting deionized water is as simple as connecting to a faucet

Benchtop, space-saving design

Digital display for easy operation

Deionized water compliant with ASTM D1193 Type 2 / JIS K 0557 A3 level, suitable for trace analysis

Displays replacement of consumables

Standard equipped with membrane filter (WL200/220)

A solenoid valve at the water sampling port prevents water leakage from final membrane filter

Specifications

Item Code

253627

Model

WL200

Water purifying method

Ion-exchange (Controlled by key)

Raw water supply

One touch coupler water connection resin hose

Deionized water production

Approx. 1L/min. (Continuously produced)

Ion-exchange resin cartridge

2L ion-exchange resin with activated carbon (CPC-P) x 1pc.

Final filtration

0.1μm (Membrane filter)

Pure water tank

N/A

Water leakage detection

Solenoid valve forced shutdown of water supply by detecting water leakage

Raw water pressure range

0.5 to 5x100kPa (0.5 to 5 kgf/cm2)

Sampling port

250mm above floor RC1/4 (Membrane filter connection)

Safety device

Circuit breaker, Water leakage indicator, Pressure reducing valve, Water quality abnormal alarm

Water quality display

7 segments LED display (Conductivity / Resistivity)

Other display

Display of consumables replacement (CPC-P and CPC-E: Should be replaced simultaneously to prevent degradation of water quality, Membrane filter), Alarm display (Water leakage alarm)

Accessories

Raw water supply hose, Power cord (2m), Ion-exchange resin CPC-P (WL200 only), Membrane filter (WL200/220), Seal tape

External dimensions（W×D×H mm）

350×350×450mm

Power Source

AC100 to 240V0.2ASingle-phase

Weight

14kg

Catalog

Water Purifier (Ion-exchange)

Optional Items

Water supply port unit(OWH10)

Membrane filter(MFRL727)

Raw water pressure reduction valve(OWG48)

*Water sampling stand (supplied in connection kit)(OWL40)

*External alarm output terminal(OWL42)

CPC-E connection set (OWL36)

*Pre-process cartridge connection set(OWL38)

*Remote water sampling function(OWL44)

Remote water sampling function with sampling switch(OWL46)

Power cord (4m)(OWL52)

Ion echange resn cartridge(CPC-P)
