System
Forced air circulation and ventilation
Operating temp. range
Room temp. +15°C~300°C
Temperature fluctuation
3.0°C (at 300°C)
Temperature slope
18°C (at 300°C)
Temperature controller
PID control
PID Z control Temp setting method
Digital setting with ▲/▼ keys
Timer
1 min~99 hrs 59 min (Resolution: 1 minute or 1 hour)
Operation function
Fixed temperature operation, Program operation (Maximum 99 steps, up to 99 patterns, repeat operation function)
Operation function
Duration/time select timer operation function (Fixed temperature operation, auto start/auto stop/quick auto stop, program operation auto start)
Additional functions
Accumulated Power on and Operation Time (up to 65,535 hours); Calendar Time (24 hours); Calibration Offset; Monitor Display of Accumulated Power Consumption,
Additional functions
Total CO2 Emission, and Heater operating Output; Power Recovery Mode; User Settings Save and Restore Function; Fan Speed Setting Function
Sensor
K-thermocouple (double sensor)
Heater
Stainless steel pipe heater with fins
Fan motor
Stainless steel axial flow fan (capacitor motor: 20W), Two motors used for Model 1032
Cable port
I.D. ø30mm (rear)
Heat insulator
Glass wool + ceramic fiber
Other additional structure
Exhaust damper (manual operation)
Safety device
Self-diagnostic functions (temp. sensor error, heater disconnection, SSR short-circuit, automatic overheat prevention), Door switch, Fan Failure Detection, key lock, independent overheat protection, electric leakage breaker with over current protection
Shelf / support
3 pcs. / 6 pcs.
Internal dimensions（W×D×H mm）
1000×1000×1000mm
External dimensions（W×D×H mm）
1700×1215×1530mm
Remarks(dimensions)
1000L
Power Source
AC220V28AThree-phase
