Water Bath (Constant Temp.)

Water Bath (Constant Temp.)(BS200)

Item Code：222061

Model：BS200

Power Source：AC115/220VSingle phase

Origin：Japan

Product Summary

Standard equipped with Overheat Prevention Device, Electric Leakage Breaker

Features

With 4 kinds of Baskets. Max. 5L Beaker can be set by removing Lid.

Specifications

Item Code

222061

Model

BS200

Operating temperature range

Room Temp. +5°C to Boiling Temp. (Water)

Temp. Adjustment Accuracy

±3°C (at 70°C )

Temp. Distribution Accuracy

±5°C (at 70°C )

Time to Reach to Constant Max. Temp

Approx. 30min

Inner Bath

Stainless Steel

Heater

Copper Pipe Heater (Nickel Plated) 900W

Safety Countermeasure

Overheat Prevention System (Liquid Expansion Type, Self SustainingRelay, Alarm Lamp On) Electric Leakage Breaker with Over CurrentProtection (Power Lamp On at the time System On)

Opening Size, Q’ty

―

Accessory

Ring (Not including BS200), Lid, Container Fixing Clamp, Stand, Bar for Clamp Fixing (Not including BS200), Connector for Stand, Thermometer (-10°C to +110°C Alcohol Type), Bottom Plate, Basket (Only for BS200)

Internal dimensions（φ×H mm）

φ200×149mm

External dimensions（W×D×H mm）

300×364×216mm

Remarks(dimensions)

Internal capacity 4.7L

Power Source

AC115/220VSingle phase

Weight

5kg
